Komunica AV-825-NF

Komunica AV-825-NF

Power Supply, Switch Mode

• Including Noise Filter

• Meter for Volt and Ampere

• Input Voltage:  90 - 125 or 200 - 240 VAC

• Output Voltage: 0 - 24 VDC

• Output Current: 9 Ampere Max

FEATURES, FUNCTIONS AND SPECIFICATIONS:

• Input Voltage: AC 90 ~ 125 or AC 200 ~ 240 inside selectable

• Output Voltage: DC .0V~ 24 V variable

• Output Voltage Regulation: Less than 1%

• Output Current: Max 9 A,

• Ripple: Less than 9 mVp-p at rated load

• Dimensions (L·W·H): 165 X 147 X 55  mm

• Weight: 1.2 kg

Protection

• Short Protection, Short Protection & Over Voltage Protection >16V: It will reduce the output voltage down to 0.1v Amps down to 0.4Amps and the warning led will light up. When short condition, removing it will automatic restart the power supply to normal condition.

• Over Temperature Protection: have double over temperature  protection.

PACKING INCLUDES:

1 Pc of Power Supply

1 Pc of User Manual in English and Spanish
