WOUXUN KG-UV980P
WOUXUN KG-UV980P
Dual Frequency Display, Dual Independant Operation System
Eight Bands for Receiving , Four Bands (Including SW) for Transmitting
Twin Band / Same Band Simultaneous Reception
999 Memory Channels
Front Panel And Radio Body Flexible For Separation
QT/DOT Encoding And Decoding
QT/DOT Scanning
Non-standard CTCSS/DCS Setting Freely
Same Band Repeat on Two Combined Radios
Dual Track And Multi-way Loudspeakers
Hand Microphone DTMF With Loudspeakers
Caller ID Display
DTMF Encoding And Decoding
Multiple Scanning Ways
Group Calls, All Calls And Selective Calls
8 Groups of Scrambler
Priority Channel Scanning
APO Power Management
Wide / Narrow Bandwidth Selectable
Chinese or English Voice Guide
Automatic Temperature Detection
Stun / Kill Function
Single Audio Pulse Frequency
Multiple Back Light Color Selectable
Scan Channel Adding / Deleting
Grouping Channel Scanning
Multiple Setting for Cooling Fan
Superheterodyne Receiver Type
Frequency range
Suitable For Different Countries or Areas
TX , FM
26-29.995MHz / 50-53.995MHz
136-174.995MHz / 400-479.995MHz
RX , FM
26-29.995MHz / 50-54.995MHz / 65-108MHz
108-180.995MHz / 320-349.995MHz
400-479.995MHz / 700-987.995MHz
RX , AM
108MHz-136MHz
Receiver
Adjacent Channel Selectivity: wide ?70dB / narrow ?60dB
Inter Modulation: wide ?65dB / narrow ?60dB
Spurious Response: wide ?70dB / narrow ?70dB
Audio Response: wide +1~-3dB(0.3~3KHz) / narrow +1~-3dB(0.3~3KHz)
Signal to Noise Ratio: wide ?45dB / narrow ?40dB
Audio Distortion: ?5%
Audio Power: transceiver ?3w / hand microphone ?1w
Sensitivity UHF/VHF: 0.25µV (12dB SINAD)
Transmitter
Adjacent Channel Power: wide ?70dB / narrow ?60dB
Type of Modulation: wide 16K F3E / narrow 11K F3E
Spurious: wide ?60dB / narrow ?60dB
Signal to Noise Ratio: wide ?40dB / narrow ?36dB
Audio Response: wide +1~-3dB(0.3~3KHz) / narrow+1~-3dB(0.3~3KHz)
Output Power: VHF (5W/10W/25W/50W) / UHF (5W/10W/25W/40W)
Package includes:
Wouxun KG-UV980 radio
Wouxun MMO-003 hand microphone
Inclined switchboard panel
Flat switchboard panel
Mounting bracket
Remote front panel bracket
Front panel extension cable
Power DC cord
Screw sets + microphone holder
2x extra fuses
